New & Original Silicon PNP Power Transistors, TO-220C package 2SB861

Product Categories

Anterwell Technology Ltd.

Contact Now

Name: New amp Original Silicon PNP Power Transistors TO220C package 2SB861
Brand: Anterwell
Price: 1 USD

Brand Name : Anterwell

Model Number : 2SB861

Certification : new & original

Place of Origin : original factory

MOQ : 20pcs

Price : Negotiate

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 9000pcs

Delivery Time : 1 day

Packaging Details : Please contact me for details

Collector-base voltage : -200 V

Collector-emitter voltage : -150 V

Emitter-base voltage : -6 V

Collector current : -2 A

Collector current-Peak : -5 A

Junction temperature : 150 ℃

Storage temperature : -45~150 ℃

package : TO-220C package

Contact Now

Silicon PNP Power Transistors 2SB861

DESCRIPTION

·With TO-220C package

·Complement to type 2SD1138

APPLICATIONS

·Low frequency power amplifier color TV vertical deflection output

PINNING

PIN	DESCRIPTION
1	Emitter
2	Collector;connected to mounting base
3	Base

Absolute maximum ratings(Ta=25℃)

SYMBOL	PARAMETER	CONDITIONS	VALUE	UNIT
V_CBO	Collector-base voltage	Open emitter	-200	V
V_CEO	Collector-emitter voltage	Open base	-150	V
V_EBO	Emitter-base voltage	Open collector	-6	V
I_C	Collector current		-2	A
I_CP	Collector current-Peak		-5	A
P_C	Collector power dissipation	T_a=25℃	1.8	W
P_C	Collector power dissipation	T_C=25℃	30	W
T_j	Junction temperature		150	℃
T_stg	Storage temperature		-45~150	℃

PACKAGE OUTLINE

New & Original Silicon PNP Power Transistors, TO-220C package 2SB861

Fig.2 Outline dimensions (unindicated tolerance:±0.10 mm)

New & Original Silicon PNP Power Transistors, TO-220C package 2SB861
